Answers of CCNA 1 v5.0 Pretest Exam

Solution of CCNA 1 v5.0 Pretest Exam

1.

2. The failure rate in a certain brand of network interface card has been determined to be 15%. How many cards could be expected to fail in a company that has 80 of the cards installed?
10
12*
15
8

3. If a technician uses an average of 2 cans of compressed air per week for cleaning, how many cans should be ordered for 8 technicians over the next 10 weeks?
16
20
200
80
160*

4. A local real estate company can have its 25 computer systems upgraded for $1000. If the company chooses only to upgrade 10 systems, how much will the upgrade cost if the same rate is used?
$100
$200
$400*
$600
$500

5. Convert the decimal number 231 into its binary equivalent. Select the correct answer from the list below.
11100111*
11100101
11101110
11110110
11011011
11110010

6. Which is a characteristic of the Internet?
It is not centrally governed.*
It is localized to specific geographic locations.
It uses only physical addresses.
It uses private IP addressing.

7. Which command can be used to test connectivity between two computers that are attached to a network?
nbtstst -s
ifconfig
winipcfg
ping*
ipconfig

8. Which two devices provide permanent data storage? (Choose two.)
hard drive*
keyboard
Blu-Ray disc*
RAM
monitor

9.

10. Convert the binary number 10111010 into its hexadecimal equivalent. Select the correct answer from the list below.
A1
BA*
85
B3
1C
90

11. What is a function of the BIOS?
provides graphic capabilities for games and applications
provides temporary data storage for the CPU
enables a computer to connect to a network
performs a power-on self test of internal components*

12. A person-hour is the amount of work that the average worker can do in one hour. It is anticipated that a company-wide system upgrade will take approximately 60 person-hours to complete. How long will it take five technicians to perform the refresh?
8 hours
10 hours
5 hours
12 hours*

13.



14.

15.

16. A company is expanding its business to other countries. All branch offices must remain connected to corporate headquarters at all times. Which network technology is required to support this requirement?
MAN
WAN*
WLAN
LAN

17. Which subnet would include the address 192.168.1.96 as a usable host address?
192.168.1.64/29
192.168.1.64/26*
192.168.1.32/28
192.168.1.32/27

18. What is the purpose of having a converged network?
to achieve fault tolerance and high availability of data network infrastructure devices
to reduce the cost of deploying and maintaining the communication infrastructure*
to provide high speed connectivity to all end devices
to make sure that all types of data packets will be treated equally

19. A user is having problems accessing the Internet. The command ping www.cisco.com fails. However, pinging the IP address of cisco.com with the command ping 198.133.219.25 is successful. What is the problem?
The default gateway is incorrect.
There is a problem with DNS.*
The address of the ARP cache is incorrect.
The web server is down.

20.

Refer to the exhibit. Host_A is preparing to send data to Server_B. How will Host_A address the packets and frames that will carry this data? (Choose two.)
The packet destination will be addressed with the IP address of the Router_B interface that is attached to Router_A.
The frame destination will be addressed with the MAC address of Server_B.
The packet destination will be addressed with the IP address of Server_B.*
The frame destination will be addressed with the MAC address of Switch_A.
The packet destination will be addressed with the IP address of the Router_A LAN interface.
The frame destination will be addressed with the MAC address of the Router_A LAN interface.*

21. Which three IP addresses are private ? (Choose three.)
10.1.1.1*
224.6.6.6
172.32.5.2
172.16.4.4*
192.167.10.10
192.168.5.5*

22. What is the general term that is used to describe a piece of data at any layer of a networking model?
segment
frame
protocol data unit*
packet

23. Which function is provided by TCP?
detection of missing packets*
path determination for data packets
communication session control
data encapsulation

24. Which option shows the proper notation for an IPv6 address?
2001.0db8.3c55.0015.abcd.ff13
2001-0db8-3c55-0015-abcd-ff13
2001,0db8,3c55,0015,abcd,ff13
2001:0db8:3c55:0015::abcd:ff13*

25.

Refer to the exhibit.
Using the network in the exhibit, what would be the default gateway address for host A in the 192.133.219.0 network?
192.133.219.1*
192.133.219.0
192.135.250.1
192.31.7.1

26. Which technology provides a solution to IPv4 address depletion by allowing multiple devices to share one public IP address?
NAT*
DHCP
SMB
HTTP
ARP
DNS

27. A technician uses the ping 127.0.0.1 command. What is the technician testing?
the TCP/IP stack on a network host*
connectivity between two adjacent Cisco devices
connectivity between two PCs on the same network
physical connectivity of a particular PC and the network
connectivity between a PC and the default gateway

28. What is the purpose of ICMP messages?
to ensure the delivery of an IP packet
to inform routers about network topology changes
to provide feedback of IP packet transmissions*
to monitor the process of a domain name to IP address resolution

29. Which basic process is used to select the best path for forwarding data?
encapsulation
addressing
routing*
switching

30. Which wireless security procedure should be used to hide the WLAN ID from wireless clients?
Configure WEP only on the access point.
Configure MAC address filtering on the access point.
Decrease the antenna spectrum on each wireless client.
Install WAP on the wireless clients.
Disable the broadcast of the SSID on the access point.*

31. What statement describes the function of the Address Resolution Protocol?
ARP is used to discover the MAC address of any host on the local network.*
ARP is used to discover the IP address of any host on the local network.
ARP is used to discover the IP address of any host on a different network.
ARP is used to discover the MAC address of any host on a different network.

32. A home user is looking for an ISP connection that provides high speed digital transmission over regular phone lines. What ISP connection type should be used?
dial-up
cell modem
satellite
DSL*
cable modem

33. What is an advantage of using IPv6 ?
higher bandwidth
more addresses for networks and hosts*
more frequencies
faster connectivity

34. Which device should be used for enabling a host to communicate with another host on a different network?
router*
hub
switch
host

35. What is the purpose of the routing process?
to encapsulate data that is used to communicate across a network
to select the paths that are used to direct traffic to destination networks*
to convert a URL name into an IP address
to provide secure Internet file transfer
to forward traffic on the basis of MAC addresses

36. Which type of connector does a network interface card use?
DIN
RJ-11
RJ-45*
PS-2

37. Why would a network administrator use the tracert utility?
to display the IP address, default gateway, and DNS server address for a PC
to check information about a DNS name in the DNS server
to determine the active TCP connections on a PC
to identify where a packet was lost or delayed on a network*

38. How does a networked server manage requests from multiple clients for different services?
The server uses IP addresses to identify different services.
Each request is tracked through the physical address of the client.
The server sends all requests through a default gateway.
Each request is assigned source and destination port numbers.*

39. Which protocol translates a website name such as www.cisco.com into a network address?
FTP
DHCP
HTTP
DNS*

40.

Refer to the exhibit. Consider the IP address configuration shown from PC1. What is a description of the default gateway address?
It is the IP address of the Router1 interface that connects the PC1 LAN to Router1.*
It is the IP address of Switch1 that connects PC1 to other devices on the same LAN.
It is the IP address of the Router1 interface that connects the company to the Internet.
It is the IP address of the ISP network device located in the cloud.
